Product Details

The Anderson Connector & Cable set offers three connector options for connecting solar panels and power stations: an Anderson extension cable and two Anderson Y-style connectors. Each option is built for reliable DC power transfer and simple field connections.

Connector options: Anderson Extension Cable, Anderson Y Parallel Connector, Anderson Y Series Connector
Compatibility: designed for use with SolarSaga 100 Prime and SolarSaga 500 X solar panels and similar systems (ensure total system voltage does not exceed 120 volts)
Extension cable length: 10 feet
Y connector length: 7.5 inches each
Designed for easy parallel or series panel connections and extension runs

Use Cases

Extend solar panel reach to a power station or charge controller
Parallel two panels using the Y parallel connector
Combine panel outputs using the Y series connector when appropriate

Notes

Verify system voltage before connecting; do not exceed 120 volts total.

Applicable models: Explorer 600 Plus/ Explorer 1000 V2

A single DC input port supports a maximum of 2 SolarSaga 100 Prime panels in series. The Explorer 600 Plus supports up to 2 SolarSaga 100 Prime panels, and the Explorer 1000 V2 supports up to 4 SolarSaga 100 Prime panels. The connection diagram is as follows:

Applicable model: Explorer 1500

A single DC input port supports a maximum of 2 SolarSaga 100 Prime panels in parallel. The Explorer 1500 supports up to 4 SolarSaga 100 Prime panels. The connection diagram is as follows:

Applicable model: Explorer 1000 Plus

A single DC input port supports a maximum of four SolarSaga 100 Prime panels in a series–parallel combination. The Explorer 1000 Plus supports up to eight SolarSaga 100 Prime panels. The connection diagram is as follows:

Applicable models: Explorer 2000 Plus/Explorer 2000 Pro/Explorer 3000 Pro

A single DC input port supports a maximum of 6 SolarSaga 100 Prime panels in series and parallel combination. The Explorer 2000 Plus/Explorer 2000 Pro/Explorer 3000 Pro supports up to 12 SolarSaga 100 Prime panels. The connection diagram is as follows:
